Vortex induced vibrations (VIV) around circular cylinder
Start
Instructions:
Keep mass of the cylinder constant as 1 Kg
Maintain the stiffness of the system at 70 N/m
Select the velocity of the vortex
Click submit to measure vortex induced vibration
Rotate the model to view 360
Vortex induced vibrations (VIV) around circular cylinder
Strouhal Number (S):
0.2
Cylinder diameter (C):
0.4 m
Mass of Cylinder (M):
Kg
Stiffness of the System (K):
N/m
Select Velocity (m/s):
--SELECT--
0.5
1
1.5
2
2.5
3
3.5
4
4.5
5
5.5
Max. 5.5
Mechanical frequency (Hz):
1
2Π
√
K ⁄ M
= 1.33
Submit
Restart
